Leverage the power of Gen AI to transform semiconductor development. HCLTech’s Progenix accelerates design verification, test case generation, and automated code development, reducing design cycles by 50-60%. With AI-driven optimization, semiconductor companies can shorten time-to-market while improving quality and efficiency.

Seamless, end-to-end silicon development from the initial product concept through to high-volume production. HCLTech’s platform-driven approach ensures faster design realization and achieves first-time-right results in silicon production, facilitated by design verification and physical design, FPGA prototype, emulation & pre-silicon validation, advanced packaging & production testing, and post-silicon validation & qualification.

With 80% of chip development effort spent on verification, AI-driven automation is a game changer. Our AI-powered verification & validation platform accelerates functional verification, automated test generation, and coverage analysis, reducing effort and increasing accuracy—leading to faster, more reliable silicon tape-out.

The next evolution in semiconductor design involves modular chiplets and heterogeneous integration. Expertise in chiplet architecture & integration, advanced packaging, and D2D interconnect solutions, along with support for post-silicon validation for multi-die parts, helps the semiconductor industry build production-proven, scalable, and power-efficient architectures.

Maximize production efficiency with AI-powered digital twins. These solutions empower fabs and OSATs with real-time monitoring and predictive maintenance, AI-driven process control, and defect detection. Initiatives in yield optimization and throughput enhancement further contribute to this robust framework. Together, these advancements lead to fewer defects, reduced downtime, and higher profitability in semiconductor manufacturing.
